Homag Optimat KAL 330 edgebander
Kaiserslautern
If you decide to buy equipment at a low price, make sure that you communicate with the real seller. Find out as much information about the owner of the equipment as possible. One way of cheating is to represent yourself as a real company. In case of suspicion, inform us about this for additional control, through the feedback form.
Before you decide to make a purchase, carefully review several sales offers to understand the average cost of your chosen equipment. If the price of the offer you like is much lower than similar offers, think about it. A significant price difference may indicate hidden defects or an attempt by the seller to commit fraudulent acts.
Do not buy products which price is too different from the average price for similar equipment.
Do not give consent to dubious pledges and prepaid goods. In case of doubt, do not be afraid to clarify details, ask for additional photographs and documents for equipment, check the authenticity of documents, ask questions.
The most common type of fraud. Unfair sellers may request a certain amount of advance payment to “book” your right to purchase equipment. Thus, fraudsters can collect a large amount and disappear, no longer get in touch.
- Transfer of prepayment to the card
- Do not make an advance payment without paperwork confirming the process of transferring money, if during the communication the seller is in doubt.
- Transfer to the “Trustee” account
- Such a request should be alarming, most likely you are communicating with a fraudster.
- Transfer to a company account with a similar name
- Be careful, fraudsters may disguise themselves as well-known companies, making minor changes to the name. Do not transfer funds if the company name is in doubt.
- Substitution of own details in the invoice of a real company
- Before making a transfer, make sure that the specified details are correct, and whether they relate to the specified company.
Seller's contacts
+49 162 58...
Show
+49 162 5858448
Germany, Frankfurt
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Pullach
Edgebander parts
Location: DE
Top pressure: driven belt
Minimum working width: 55 mm at 22 mm thickness; 100 mm at 60 mm thickness (depending on workpiece length)
Edge material from strip: 0.4–20 mm (max cross-section 900 mm²)
Edge material from coil: 0.3–3 mm (max cross-section: PVC 135 mm², veneer 100 mm²)
Pre-milling unit: 2 motors, each 4 kW, 150 Hz, 9000 rpm; electro-pneumatic control
Pneumatic trimming motor adjustment (2 positions: flush/level and with overhang for contour milling)
Rough milling unit: 2 motors stacked, each 1.5 kW, 200 Hz, 12,000 rpm; height adjustment via top pressure
Pneumatic 2-position setting: roughing with ~0.2 mm overhang / without overhang
Universal milling units: 2x UF11 controlled
Cleaner 08 top/bottom: rotating linear brushes for surface cleaning
Control: Power Control PC22
Infeed table: HOMAG Optimat TBL 100/10/16, fix stop left
Approx. dimensions: length ~1000 mm; width 1800 mm
Workpiece return: LIGMATECH ZHR30 “Boomerang” (standard return for large pieces)
Workpiece capacity: length 250–3000 mm; width 250–1200 mm; thickness 8–60 mm; max weight 60 kg
Workpiece dimensions for turning: length 50–200 mm; width 300–800 mm
Belt cleaning (single): fixed brush line
Line workpiece capacity
Length 250–3000 mm
Width 120–1200 mm
Thickness 8–60 mm
Edge bander (KAL 330) — base and transport
Continuous machine base
workpiece support with roller bar extendable ~800 mm
Transport chain 80 mm wide with rubber surface
precision guidance
hardened surfaces
Technical data
Feed speed 18–25 m/min
Working height 950 mm
Workpiece overhang/supernatant 30 mm
Workpiece thickness 12–60 mm
Max coil diameter 830 mm
Pneumatic connection 7–8 bar
Infeed system and controls (integrated with KAL 330)
Flexible workpiece infeed system wz10 for automatic infeed (lengthwise and crosswise)
for precisely sized
square parts
Stepless infeed guidance adjustment (axis)
speed set at input terminal
Automatic side adjustment of units (workpiece overhang 30–80 mm) for gluing and post-processing
Input terminal
solvent applicator top/bottom
Edge preparation and gluing
Stepless vertical axis SF20 for automatic centering to panel thickness
Pre-melting unit with granule storage
Quick-lock system for QA/QE application unit
QA front glue storage for color change
Basic gluing unit A20
magazine height adjustment ±5 mm (manual spindle)
Extended magazine A6/A-E12/A20 for 2 coils (max Ø 830 mm)
preheating station for QA/QE
Automatic pressure zone adjustment
Trimming and milling
Trimming unit HL84 with standing trimming stop for sensitive edges
Pneumatic chamfer/straight changeover
manual side trimming stop adjustment when edge thickness changes
Reserved free space for a fine milling unit
Contour milling unit Servo FK13 automatic
2 motors each 0.4 kW
200 Hz
12,000 rpm
Servo-controlled movements
automatic 8-fold tool changer
Feed speed max 20 m/min
minimum spacing between workpieces 500 mm
Workpiece thickness 12–60 mm
Automatic FK adjustment for identical radii on different edge thicknesses
auto retract
FK workpiece guidance with additional clamping for min part length 120 mm (single-sided)
Finishing and cleaning
Multi cleaning unit MN21 automatic
Up to 3 profiles
tracing from top/bottom/side for chamfer and rounding on pre-milled PVC edges
Electropneumatic air nozzles
automatic chamfer/radius changeover
auto retract of upper/lower tool
Height adjustment via top pressure
PVC shavings separator top/bottom
Finish unit FA11 top/bottom
Cleaning device with carbide knife
height adjustment via top pressure
Cleaning solvent spray
buffing unit
electropneumatic flat scraper control
Swiveling to max 90°
motor 6 kW
30 mm shaft
motor positions horizontal/vertical
Stepless horizontal and vertical axes for each UF11
Belt sanding unit KS10 for straight edges
belt speed 10 m/s
oscillation
Automatic adjustment to edge thickness
auto retract
stepless torque adjustment
Additional equipment
Technical data
Workpiece length min 120 mm
length max (for TBL100/25/12) 2500 mm
Workpiece width min 195 mm
max 1200 mm
Roller Ø 50 mm
roller spacing ~120 mm
Stepless feed speed 7–40 m/min
Side guidance with steplessly adjustable rollers
1 air table 1700 × 650 mm
Enables 1-person operation of single-sided throughfeed machines
Lifting device at outfeed to level parts with the infeed air table
Pintles for small parts
sensor-controlled (automatic positioning) for easy turning
